T6000 Electro Pneumatic Transducer

T6000 Electro Pneumatic Transducer-Data Sheet (PDF Download)

The T6000 Series Electro Pneumatic Transducer is designed for precision applications providing maximum versatility. The modular construction permits any basic unit to be used in the explosion-proof,rack, wall, pipe, panel, DIN rail or 3, 5, 10, or 15 unit manifold configurations. Servicing or calibration is quick and easy.

Features

• Field reversible feature provides output which is directly or inversely proportional to

the input signal.

• RFI/EMI Protection eliminates susceptibility to electromagnetic and radio interference.

• Six output pressure ranges meet final control element requirements.

• Six input signal ranges meet most process and machine requirements.

• Compact size permits use in space restricted areas.

• Explosion-Proof NEMA 4X, IP65, Type 4 Enclosure available for outdoor and indoor

installations.

• Input and Output ports on both front and bottom simplifies pneumatic piping.

The electro pneumatic converter is an accessory for a pneumatic control valve with a compact structure and single function. Its control accuracy and use effect are far less accurate than the valve positioner. It has been gradually eliminated by the valve positioner, but the working principle and components of the electro pneumatic transducer are typical The structure of the pneumatic instrument is basically the same as the core components of the valve positioner. Therefore, it is not useless to be familiar with the electro converter. Mastering the principle of the electro converter is also useful for the maintenance of complex valve positioning on site.
